DFSK EC35 Electric MINI VAN

Product Paramenters

LWH (mm)	450016801985
Wheel (mm)	3050
Track (mm)	1435/1435
Curb weight (kg)	1670
G.V.W (kg)	2510
0-50km/h acceleration	≤7S
0-100kW/h acceleration	≤28S
Max speed (km/h)	105
Seats	2/2+3
Driving and Axle
Motor	permanent magnet synchronous motor
Cooling	water
Max/rated power (KW/rpm)	30/3000，60/8500
Max/rated torque（N.m）	95.5 /191
Axle ratio	43:10
Drive range (semi-loaidng, km)	≥233
Voltage（V）	320
Battery capacity (kWh)	41.4
Gear	AT
Car charger	independent type, 6.6kw
DC-DC converters	1kw，with CAN
Plug and scoket	According to international standard GBT 20234.1-2015（General use） GBT 20234.2-2015（AC slow charging interface） GBT 20234.3-2015（DC quick charging interface） GBT 18487.1-2015（general charging） 13Ah slow charging plug

Overview

Quick Details

Place of Origin:

China

Brand Name:

Dongfeng Sokon

Product name:

EC35 New Energy vehicle electric van Mini EV van

Length width height (mm):

4500*1680*1985

Motor Type:

Permanent Magnet Sychronus Motor

Battery Capacity (kWh):

CATL:42

Battery Pack:

CATL Battery, Lithum Iron Phosphate Battery

NEDC Max. Mileage(km):

≥300

Rated Power(kw):

30/3600

Peak Power (kw)/Peak Torque(rpm):

60/9000

Rated Troque(N.m)/Max. Torque(N.m):

80/200

Charge Time(hrs):

Fast Charge: SOC(20%-80% )1.3hrs/(0-100%)2.5hrs, Slow Charge: 7-8hrs

Packaging & Delivery

Product Description

EC35 New Energy vehicle electric van Mini EV van

Packing & Delivery

any port in China
